Most sizes currently in stock! Damper will be tuned to you and your bike when you order, please put your weight, bike, riding style and whether you ride flats or clips in the note section of the order. Feel free to reach out if you have any questions!
Spring rates will be calculated by us and add to the order after purchase (included in price shown below). At checkout, use the 'Add special instructions' option to add rider weight, bike model and year and riding style (as well as any other information you think is important).
- Metric and Imperial sizing – Standard or Trunnion mount
- 4 way adjustable (LSC-HSC-LSR-Lok proprietary system)
- High flow Ø29 mm main piston
- 24 mm valve piston
- 14 mm shaft
- New Lok Technology – Progressive opening – Silent working
- Engineered rebound circuit to separate bump and rebound oil flow
- Ultra low-friction coating
- Factory tuned HBC technology
- Very low reservoir pressure for maximum sensitivity (55 PSI)
- Full custom hydraulic setup available
- No cavitation
- Very low hysteresis for high dynamic response
- High turbulent flow for very low temperature depending
- Low friction Energize seal
- Thinner bottom-out bumper
- New rebound knob for easy spring swap
Weight: 636 gr.
(200×57 mm. Standard mount – 375 lbs. spring)
AVAILABLE LENGTHS / STROKE
IMPERIAL
190 / 51 mm
200 / 57 mm
216 / 63.5 mm
222 / 67 mm
METRIC STANDARD
210 / 50 mm
210 / 52.5 mm
210 / 55 mm
230 / 57.5mm
230 / 60 mm
230 / 62.5 mm
230 / 65 mm
250 / 67.5 mm
250 / 70 mm
250 / 72.5 mm
250 / 75 mm
METRIC TRUNNION
185 / 50 mm
185 / 52.5 mm
185 / 55 mm
205 / 57.5 mm
205 / 60 mm
205 / 62.5 mm
205 / 65 mm
225 / 67.5 mm
225 / 70 mm
225 / 72.5 mm
225 / 75 mm
We are also an authorized service centre for EXT, get in touch if you need your shock serviced or retuned!
