SQLab 602 ERGOLUX Active 2.1 Saddle

ERGOLUX® stands for maximum comfort

The 602 ERGOLUX® active 2.1 is designed for a more upright riding position. Its shape is optimized for long-distance trekking and everyday city rides, offering high comfort with every pedal stroke. Ideal for riders who value support and pressure distribution on relaxed tours and daily commutes. The 602 ERGOLUX® active 2.1 was designed for trekking cyclists seeking both comfort and pressure relief. Its two-stage ERGOLUX® profile provides support for the sit bones while reducing pressure in the perineal and soft tissue areas – perfect for long days in the saddle. With the active System 2.1 and high-quality padding, it is perfectly suited for fitness rides and light touring.

Saddle Width System: perfect fit
A prerequisite for maximum comfort and relief is the matching saddle width, so that it is ensured that your sit bones lie fully on the saddle. Because only then, the sensitive perineal area in men and the usually lower pubic arch in women can be properly relieved.

ERGOLUX®: pressure relief
The lower saddle nose in combination with the slight depression in the middle relieves the sensitive perineal area. The flat, only very slightly curved shape of the saddle nose results in a maximum contact surface with correspondingly less pressure.

Active-Technology: Back-friendly
The SQlab active saddle technology enables a physiological co-movement of the pelvis. Spinal discs and facet joints can thus be relieved. In particular, the mobilization of the spincal discs is clearly noticeable. SQlab introduces the next evolutionary stage of active technology. The active movement 2.1 can be adjusted via the switch function as of now in two stages and this is child's play.

ERGOLUX® stands for maximum comfort
The two-stage ERGOLUX® shape provides balanced pressure distribution between the sit bones and perineal area. The pressure on the sit bones is distributed over a very large area due to the wave shape. The difference in height between the sit bone support and perineal area is less than with the M-D Line, which is consistently designed to relieve pressure. The 602 ERGOLUX® active 2.1 has a relief of 65%.

M-D Line stands for maximum relief
The M-D Line was developed for maximum relief of sensitive areas. A pressure distribution according to medical aspects. M-D Line stands for maximized dip. In combination with the high classic step shape, distributes the body weight to the sit bones. The 602 M-D active 2.1 has a relief of 80%.

Features

• ERGOLUX® Shape – Two-stage contour for comfort and stability
• Active System 2.1 – Natural pelvic movement for spinal health
• Firm Padding – Comfort without sinking
• Touring-ready – Ideal for fitness and trekking cyclists

Tech Specs

• Producer's weight: 470 g (14 mm) / 480 g (15 mm)/ 490 g (16 mm) / 500 g (17 mm)
• Length: approx. 282 mm
• Effective height: approx. 75 mm
• Active technology: Yes - Comfort
• Material rails: CrMo (solid)
• Material base: Polypropylene Compound (PP)
• Material padding: Light Foam
• Material cover: Durable Microfibre
• Hardness in sq-shore: 45
• Relief of perineal area in %: 65
• Maximum load in kg: 130
• Maximum torque in nm: 18
