Concave & Grippy
Without an axle underfoot, the shoe is free to flex a small amount, offering an exceptional amount of grip on the pins and a locked-in pedal feel
Exceptionally Thin
9.85mm thin, 115mm x 115mm platform
Strong & Serviceable
Our pedal bodies are made out of 7075 aluminum. Each pedal houses two robust oil filled 7902 bearings. Total pedal weight is 229g
- Outlier recommends these pedals for shoes size 7 US men's, 8.5 US women’s, 40 EU, 7 UK and larger
- Please torque our pedals to 30-35NM. Do not overtorque
- Certain cranks and crank boot combinations may require a pedal washer
- Outlier offers a 2 year warranty on bodies, axles and spacers
- Installation and Maintenance Guide
Specs
-
Platform Size: 115mm long and 115mm wide (100mm end of axle to outside edge)
-
Thickness: 9.85mm
-
Material: 7075 Aluminum
-
Pins: 18 per pedal (9 per side), M4 (tapered head), protrude 5.71mm, 4 extra pins provided
-
Bearings: 7902
-
Colours: Black // Raw (Clear Anodized)
-
Weight: 458g per pair
